Copeland ZR250KCE-TWD-523 Scroll Compressor for Air Conditioning/Heat Pumps R134A/R407C
Copeland Emerson Buy products online for less: Compressor Copeland ZR250KCE TWD 523 // Fast worldwide delivery
- R22 A1 GWP 1,810
- R134a A1 GWP 1,430
- R407C A1 GWP 1,774
Technical data
Performance
- Cooling capacity i
- 52,2 kW
- Performance at operating conditions i
- 5°C evap, temp,; 50°C cond, temp,; 10 K suction superheat; 0 K subcooling for R-407C at 50 Hz
- Displacement
- 56,6 m³/h
Refrigerant & oil
- Refrigerant
- R22, R134a, R407C
- Oil
- vorgefüllt, POE
- Oil quantity
- 4,70 l
Operating range
- Area of application i
- AC, HBP, MBP
Electrical
- Voltage
- 380-420V, 460V
- Electronics
- inkl.
- Max. operating current
- 42 A
Connections
- Discharge line
- 1 3/8" (34,9 mm)
- Suction line
- 1 5/8" (41,3 mm)
Dimensions & weight
- Dimensions (L × W × H)
- 43,2 × 37,6 × 71,7 cm
- Weight
- 140 kg
General
- Frequency
- 50-60 Hz
- Motor code
- TWD
- Number of phases
- 3
- Product family
- ZR
- Recommended crankcase heater
- 120
- Type of compression
- Scroll
- Type of construction
- Hermetic
- dbA @ 1m
- 72
Description
Copeland ZR250KCE-TWD-523 Scroll Compressor for Air Conditioning/Heat Pumps R134A/R407C
The Copeland ZR scroll compressor is designed for comfort, process and precision cooling using the refrigerants R513A, R407C and R134a. Typical applications include chillers, rooftop air-handling units and precision air-handling units. By using multiple Copeland-certified tandem and trio combinations, higher capacities can also be achieved with high seasonal efficiency.
Copeland ZR scroll compressors are designed for comfort, process and precision cooling using the refrigerants R513A, R407C and R134aTypical applications include chillers, rooftop air-handling units and precision air-handling unitsBy using multiple Copeland-certified tandem and trio combinations, even higher capacities (e.g. air-cooled chillers up to approx. 500 kW) can be achieved with high seasonal efficiencySpecial ZR models for R513A (GWP 631) are available to meet current requirements for low GWP valuesThe series covers approximately 2 HP to 30 HP (ZR24–ZR380 for R407C/R134a, ZR24KRE–ZR190KRE for R513A/R407C/R134a) and, thanks to low superheat (approx. 5 K), enables good system optimisation and cost reductionAxial and radial flexibility of the scrolls ensures high reliability and efficiencyExtensive ZR range for R407C, R134a and R513ALow TEWI (Total Equivalent Warming Impact)Low noise and vibration levelsLow oil carryoverCopeland-certified tandem and trio configurations for high seasonal efficiencyMaximum permissible operating pressure (PS): ZR24 to ZR81: ND 21 bar(g) / HD 29 bar(g)Maximum permissible operating pressure (PS): ZR108 to ZR380: ND 20 bar(g) / HD 32 bar(g)Technical details
- Dimensions (length × width × height) 43.2 × 37.6 × 71.7 cm
- Application range AC
- Application range HBP
- MBP application range
- Number of phases 3
- Design: Hermetic
- dB(A) @ 1 m 72
- Pressure line (inches) 1 3/8"
- Electronics included
- Recommended crankcase heater 120
- Frequency 50–60 Hz
- Weight 140
- Air flow rate 56.6 m³/h
- Cooling capacity (kW) 52.2
- Refrigerant R134A
- Refrigerant R22
- Refrigerant R407C
- Capacity under operating conditions: 5°C evap. temp.; 50°C cond. temp.; 10 K suction superheat; 0 K subcooling for R-407C at 50 Hz
- Max. operating current (A) 42
- Motor code TWD
- Oil pre-filled
- Oil quantity (l) 4.70
- Oil type: POE
- Product family ZR
- Suction pipe (inches) 1 5/8"
- Compression type: Scroll
- Supply voltage 380–420 V
- Supply voltage 460V
Advantages and benefits
- High reliability and efficiency thanks to the axial and radial flexibility of the scrolls
- Low noise and vibration levels ensure quiet operation
- Optimal system adaptation and cost reduction thanks to low overheating
- High seasonal efficiency thanks to certified tandem and trio configurations
Note:
- Oil: The compressor is pre-filled with oil at the factory. Refrigerant is not included and must be charged by a qualified contractor.
- Electronics: The electronics are included in the scope of supply.
Matching accessories
Matching this compressor according to the product data. Please check against the compressor manufacturer's specifications before installation.
Valves and adapters
-
€224.91*
-
Copeland 8040791 Adapter set oil + gas equalisation for ZR250K-ZR380K,ZP235K-ZP385K Item no. 73-8040791
Available
€107.94*
Alternatives compared
|
This item
Copeland ZR250KCE-TWD-523 Scroll Compressor for Air Conditioning/Heat Pumps R134A/R407C
€4,727.91
|
Invotech scroll compressor YH610T1G-100, A/C, R407C, 380-420V/3PH/50 - 460V/3PH/60Hz €2,963.10 €1,764.81 cheaper | Copeland ZR250KCE-TWD-522 Scroll Compressor for Air Conditioning/Heat Pumps R134A/R407C €4,897.98 €170.07 more | Compressor Maneurop Scroll SZ240-4A, HMBP - R404A, R507, R407C, 3F- will be replaced by SY240-4 €5,700.10 €972.19 more |
|---|---|---|---|---|
| Availability | Available | Ready to ship in approx. 14 business days | Ready to ship in approx. 7 business days | Ready to ship in approx. 7 business days |
| Area of application | AC, HBP, MBP | AC | AC, MBP, HBP | MBP/HBP |
| Refrigerant | R22, R134a, R407C | R407C | R407C, R22, R134a | R407C, R507A, R507 |
| Supply voltage | 380-420V, 460V | 460V/3Ph, 380-420V/3Ph | 460V, 380-420V | 400V |
| Cooling capacity (kW) | 52,2 | 58.03 | 52,2 | — |
| Dimensions ( length × width × height ) | 43,2 × 37,6 × 71,7 cm | 359,8x326,2x671,2 mm | 42,7 × 37,6 × 72,6 cm | — |
| Oil | vorgefüllt | vorgefüllt, Polyoesteröl (POE) | vorgefüllt | vorgefüllt |
| Stroke volume | 56,6 m³/h | — | 56,6 m³/h | 347.8 |
| Type of construction | Hermetic | Scroll | Hermetic | Scroll, Hermetic |
| view item | view item | view item |
Same for all: Electronics: inkl.
