Air-to-water monobloc heat pump R290 Decarbonize ECO-030 8.3 kW
€6,799.00*
Available, delivery time: 1-2 weeks,
within Germany, abroad different
Do you have some questions about this product?
- Your personal contact person
- Hendirk Homann
- [email protected]
- +49 2554 912 983 9
-
Nicht das gefunden wonach Sie suchen?
Jetzt Ersatzteil anfragen
Product information "Air-to-water monobloc heat pump R290 Decarbonize ECO-030 8.3 kW"
Air-to-water monobloc heat pump - Decarbonize ECO series
The Decarbonize ECO series air-to-water monobloc heat pump offers an efficient solution for heating, cooling and hot water preparation. With a focus on energy efficiency and environmental friendliness, it impresses with its sustainable aspects and intuitive operation.
We are looking for heat pump specialist partners!
We are looking for specialist partners for our DECARBONIZE heat pumps.
Are you interested? Please fill out our form: Specialist partner form
Technical details:
- Powerful: 100 % heat output at -25°C
- Efficient: Energy efficiency class A+++ (35°C) / A++ (55°C)
- Monobloc design (all-in-one appliance)
- Large power range with 4 models from 8.3 to 22 kW
- Certified quality
- Friendly models
- Environmentally friendly refrigerant R290
- Optimised defrosting
- Silenced compressor
- High-performance circulation pump
- Pressure and flow sensor in the hydraulic circuit
- Innovative control panel with touch function
- Energy and consumption recording
- Controllable via app
- Automatic, seasonal temperature adjustment
- SG-Ready
Advantages and benefits:
The Decarbo ECO series offers reliable and powerful heating performance for indoor spaces, even at extreme outdoor temperatures. With an EER range of 2.65 to 3.04 and a COP range of 3.52 to 4.69, it guarantees efficient operation and maximum energy savings. The use of the environmentally friendly refrigerant R290 with a GWP of 3 makes the heat pump future-proof and PFAS-free.
Technical data:
- Model: ECO-030
- Heating mode - ambient temperature: 7/6 degrees, water temperature: 30/35 degrees
- Heating power range: 3.3~8.3 kW
- Heating power input range: 0.64~2.18 kW
- COP range: 3.81~5.17
- Hot water mode - ambient temperature: 7/6 degrees, water temperature: 15/55 degrees
- Heating power range: 3.7~7.4 kW
- Heating power input range: 0.79~2.10 kW
- COP range: 3.52~4.69
- Cooling mode - ambient temperature: 35/24 degrees, water temperature: 12/7 degrees
- Power range: 2.4~5.8 kW
- Power input range: 0.79~2.19 kW
- EER range: 2.65~3.04
- ERP level (35°C): A+++
- ERP level (55°C): A++
- Refrigerant: R290
- Power supply: 230V/1Ph/50Hz/60Hz
- Pipe diameter: DN25
- Max. Water column: 9 m
- Lärm dB(A): <43
- Net weight: 105 kg
- Net dimensions (L/W/H): 1080x460x820 mm
- Operating ambient temperature: -20~43 degrees
Note: A cooling licence is required for work on air conditioning systems and heat pumps with F-gases. Only certified persons are authorised to carry out such work.
| Gefahrgut: | Ja |
|---|---|
| Heating capacity range in kW: | 3.3~8.3 kW |
| Refrigerant: | R290 |
| Sound level: | < 43 dB |
