Copeland ZH09KVE-TFD-526 Scroll Compressor for Heat Pumps, R407C

Copeland ZB21KCE-TFD-551 Scroll Compressor for Refrigeration R404A/R448A/R449AThe Copeland ZB21KCE-TFD-551 scroll compressor is designed for medium-temperature refrigeration applications and offers a reliable solution for various refrigerants. It features a compact and lightweight design, making it ideal for chillers and process cooling systems.Copeland ZB and ZBD scroll compressors are designed for medium-temperature refrigeration applications using the refrigerants R407A/F/C, R448A/R449A, R404A, R134a, R450A and R513AThe ZB series covers a displacement range of approximately 5.9 to 87.5 m³/hThe digital ZBD models allow for stepless capacity modulation, typically from 10 to 100 %Copeland scroll compressors have significantly fewer moving parts than reciprocating compressors and feature a set of spirals that are axially and radially flexible, making them particularly robust against operational disturbances (e.g. liquid slugging)Thanks to their compact, lightweight design, they are ideally suited for chillers, compact refrigeration systems and process coolingThe Summit models (approx. 7–15 HP) are designed for high seasonal efficiency and achieve up to around 15 % higher efficiency than comparable semi-hermetic piston compressorsIf required, an optional soundproofing hood can reduce the noise level by up to approximately 10 dB(A)Axial and radial flexibility of the scrolls ensures high reliability and efficiencyWide operating range with low condensation temperatures and rapid cooling capacitiesHigh seasonal efficiency, optimised for typical operating pointsLightweight and compact design, weighing up to about half as much as comparable semi-hermetic piston compressorsOptional soundproofing hood for additional noise reductionDigital ZBD models for stepless capacity modulation (approx. 10–100 %)one compressor type for multiple refrigerants (R407A/F/C, R448A/R449A, R404A, R134a, R450A, R513A)Maximum permissible operating pressure (PS): ZB15 to ZB45: low-pressure side 21 bar(g) / high-pressure side 32 bar(g); ZB50 to ZB114: Low-pressure side 22.6 bar(g) / High-pressure side 32 bar(g); Digital ZBD: Low-pressure side 21 bar(g) / High-pressure side 28.8 bar(g); Summit ZBD: Low-pressure side 22.6 bar(g) / High-pressure side 32 bar(g)Technical detailsMBP application rangeNumber of phases: 3Design: HermeticCOP 2.01dB(A) @ 1 m 58dB(A) 71Pressure line (inches) 1"Electronics includedRecommended crankcase heater 70Replacement for the following models: OBS ZS21K4E-TFD-551Frequency 50–60 HzWeight 27Airflow rate 8.61 m³/hCooling capacity (kW) 55Refrigerant R134ARefrigerant R22Refrigerant R404ARefrigerant R407ARefrigerant R407CRefrigerant R407FRefrigerant R448ARefrigerant R449ARefrigerant R450ARefrigerant R513ACapacity under operating conditions: -10°C evap, temp; 45°C cond, temp; 20 °C suction gas return; 0 K subcooling for R-404A at 50 HzPower consumption [kW] 2.51Max. operating current (A) 7.2Max. operating pressure ND/HD [bar(g)] 21/32Motor code TFDPre-filled with oilOil capacity (l) 1.24Oil type POEProduct family ZBSuction pipe (inches) 1 1/4"Protection class IP21Compression type: ScrollSupply voltage 380–420 VSupply voltage 460 VAdvantages and benefitsHigh reliability and efficiency thanks to the axial and radial flexibility of the scrollsOptimal performance at low condensing temperatures and with high cooling capacitiesLow weight and compact design allow for easy integration into various applicationsDigital ZBD models offer flexible capacity modulation to meet a range of requirements Note:Oil: The compressor is pre-filled with oil at the factory. Refrigerant is not included and must be charged by a qualified service technician.Electronics: The electronics are included in the scope of supply.

Copeland ZH06K1P-TFM-524 Scroll Compressor for Heat Pumps, R410A The Copeland ZH06K1P-TFM-524 is a fixed-speed heating compressor designed for heat pump and reversible applications using R410A. It offers high heating capacity and efficiency, thereby reducing the need for supplementary electric or gas-fired heating. Copeland ZH scroll compressors are fixed-speed heating compressors for heat pump and reversible applications using R410A, R407C (and, in some cases, R134a/R513A) The series is based on three platform sizes and covers a capacity range from approximately 4 kW to 38 kW ZH heating compressors are optimised for low evaporation temperatures, deliver high heating capacity and efficiency, and thus reduce the need for supplementary electric or gas heating – resulting in correspondingly better seasonal efficiency Variants with ‘Enhanced Vapour Injection’ (EVI) feature an additional connection for vapour injection during compression This extends the heating capacity and operating range and enables high flow temperatures, often making them suitable as a replacement for conventional boilers Axial and radial flexibility of the scrolls ensures high reliability High efficiency and increased heating capacity, even at low source temperatures High water temperatures for various heating systems Low noise and vibration levels Tandem configurations possible for improved seasonal efficiency Extended vapour injection (EVI) for maximum output and efficiency Maximum permissible operating pressure (PS): ZH(i)04K1P to ZH(i)23K1P: ND 28 bar(g) / HD 45 bar(g) Maximum permissible operating pressure (PS): ZHi27K1P to ZHi46K1P: ND 29.5 bar(g) / HD 53 bar(g) Maximum permissible operating pressure (PS): ZH12K4E to ZH45K4E: ND 20 bar(g) / HD 32 bar(g) Maximum permissible operating pressure (PS): ZH09KVE to ZH18KVE: ND 20 bar(g) / HD 32 bar(g) Technical details Dimensions (length × width × height) 24.2 × 24.2 × 42.2 cm Application range HBP Application range HT Number of phases 3 Design Hermetic dB(A) @ 1 m 62 Pressure line (inches) 1/2" Electronics included Recommended crankcase heater 40 Frequency 50 Hz Weight 31 Airflow 5.13 m³/h Cooling capacity (kW) 7.62 Refrigerant R410A Capacity under operating conditions: 7.2°C evap, temp; 54.4°C cond, temp; 410A at 50 Hz Max. operating current (A) 6 Motor code TFM Oil pre-filled Oil quantity (l) 1.24 Oil type: POE Product family ZH Suction line (inches) 7/8" Compression type: Scroll Supply voltage 380–420 V Advantages and benefits High efficiency and heating output, even at low source temperatures Low noise and vibration levels for quiet operation Tandem configurations enable improved seasonal efficiency Enhanced vapour injection (EVI) ensures maximum performance and efficiency Note:Oil: The compressor is pre-filled with oil at the factory. Refrigerant is not included and must be charged by a qualified contractor.Electronics: The electronics are included in the scope of supply.

Copeland ZH09K1P-TFM-524 Scroll Compressor for Heat Pumps, R410AThe Copeland ZH09K1P-TFM-524 is a fixed-speed heating compressor designed for heat pump and reversible applications using R410A. It offers high heating capacity and efficiency, thereby reducing the need for supplementary electric or gas-fired heating.Copeland ZH scroll compressors are fixed-speed heating compressors for heat pump and reversible applications using R410A, R407C (and, in some cases, R134a/R513A)The series is based on three platform sizes and covers a capacity range from approximately 4 kW to 38 kWZH heating compressors are optimised for low evaporation temperatures, deliver high heating capacity and efficiency, and thus reduce the need for supplementary electric or gas heating – resulting in correspondingly better seasonal efficiencyVariants with ‘Enhanced Vapour Injection’ (EVI) feature an additional connection for vapour injection during compressionThis extends the heating capacity and operating range and enables high flow temperatures, often making them suitable as a replacement for conventional boilersAxial and radial flexibility of the scrolls ensures high reliabilityHigh efficiency and increased heating capacity, even at low source temperaturesHigh water temperatures for various heating systemsLow noise and vibration levelsTandem configurations possible for improved seasonal efficiencyExtended vapour injection (EVI) for maximum output and efficiencyMaximum permissible operating pressure (PS): ZH(i)04K1P to ZH(i)23K1P: ND 28 bar(g) / HD 45 bar(g)Maximum permissible operating pressure (PS): ZHi27K1P to ZHi46K1P: ND 29.5 bar(g) / HD 53 bar(g)Maximum permissible operating pressure (PS): ZH12K4E to ZH45K4E: ND 20 bar(g) / HD 32 bar(g)Maximum permissible operating pressure (PS): ZH09KVE to ZH18KVE: ND 20 bar(g) / HD 32 bar(g)Technical detailsDimensions (length × width × height) 24.2 × 24.2 × 42.2 cmApplication range HBPApplication range HTNumber of phases 3Design HermeticdB(A) @ 1 m 62Pressure line (inches) 1/2"Electronics includedRecommended crankcase heater 40Frequency 50 HzWeight 33Air flow rate 6.93 m³/hCooling capacity (kW) 10.3Refrigerant R410ACapacity under operating conditions: 7.2°C evap, temp; 54.4°C cond, temp; R410A at 50 HzMax. operating current (A) 7Motor code TFMPre-filled oilOil quantity (l) 1.24Oil type: POEProduct family ZHSuction line (inches) 7/8"Compression type: ScrollSupply voltage 380–420 VAdvantages and benefitsHigh efficiency and heating output, even at low source temperaturesLow noise and vibration levels for quiet operationTandem configurations enable improved seasonal efficiencyEnhanced vapour injection (EVI) ensures maximum performance and efficiency Note:Oil: The compressor is pre-filled with oil at the factory. Refrigerant is not included and must be charged by a qualified technician.Electronics: The electronics are included in the scope of supply.

Our oil sump heater (heating cable with clamp) is the ideal replacement for the Copeland 8561105 heating cable. With an output of 70 W and a voltage of 230 V, it is the perfect fit for Copeland compressors with a diameter of 150 to 205 mm. Technical details: Power: 70 W Voltage: 230 V Diameter: 150 to 205 mm Advantages and benefits: Our oil sump heater provides reliable heat for your Copeland compressor to ensure optimum performance. With easy installation and efficient heat transfer, it keeps your system running smoothly and protected from cold damage.

Copeland ZH26K4E-TFD-524 Scroll Compressor for Heat Pumps R134A/R407CThe Copeland ZH scroll compressor is a fixed-speed heating compressor designed for heat pump and reversible applications using R410A, R407C (and, in some cases, R134a/R513A). It offers high heating capacity and efficiency, thereby reducing the need for supplementary electric or gas-fired heating.ZH heating compressors are optimised for low evaporation temperatures, deliver high heating capacity and efficiency, and thus reduce the need for supplementary electric or gas-fired heating – resulting in correspondingly better seasonal efficiencyVariants with ‘Enhanced Vapour Injection’ (EVI) feature an additional connection for vapour injection during compressionKey features:Axial and radial flexibility of the scrolls for high reliabilityHigh efficiency and increased heating output, even at low source temperaturesHigh water temperatures for various heating systemsLow noise and vibration levelsTandem configurations possible for improved seasonal efficiencyExtended vapour injection (EVI) for maximum output and efficiencyMaximum permissible operating pressure (PS):ZH(i)04K1P to ZH(i)23K1P: ND 28 bar(g) / HD 45 bar(g)ZHi27K1P to ZHi46K1P: ND 29.5 bar(g) / HD 53 bar(g)ZH12K4E to ZH45K4E: ND 20 bar(g) / HD 32 bar(g)ZH09KVE to ZH18KVE: ND 20 bar(g) / HD 32 bar(g)Technical detailsDimensions (length × width × height) 24.3 × 24.2 × 40 cmApplication range HBPApplication range HTNumber of phases 3Design HermeticCOP 3.53dB(A) @ 1 m 63dB(A) 75Pressure line (inches) 1/2"Electronics includedRecommended crankcase heater 70Frequency 50–60 HzWeight 28Air flow rate 10 m³/hCooling capacity (kW) 9.99Refrigerant R134ARefrigerant R407CCapacity at operating conditions: 7.2°C evap, temp; 54.4°C cond, temp, for R407C at 50 HzPower consumption [kW] 1.96Max. operating current (A) 7Max. operating pressure ND/HD [bar(g)] 22.6/32Motor code TFDPre-filled with oilOil capacity (l) 3.10Oil type POEProduct family ZHSuction pipe (inches) 3/4"Compression type: ScrollSupply voltage 380–420 VSupply voltage 460VAdvantages and benefitsHigh efficiency and heating output, even at low source temperaturesLow noise and vibration levels for quiet operationOptimised performance through enhanced vapour injection (EVI)Tandem combinations enable improved seasonal efficiency Note:Oil: The compressor is pre-filled with oil at the factory. Refrigerant is not included and must be charged by a qualified contractor.Electronics: The electronics are included in the scope of supply.

Copeland ZH18KVE-TFD-526 Scroll Compressor for Heat Pumps, R407CThe Copeland ZH18KVE-TFD-526 is a fixed-speed heating compressor designed for heat pump and reversible applications using R410A, R407C (and, in some cases, R134a/R513A). It offers high heating capacity and efficiency, thereby reducing the need for supplementary electric or gas-fired heating.ZH scroll compressors are fixed-speed heating compressors for heat pump and reversible applications using R410A, R407C (and, in some cases, R134a/R513A)The series is based on three platform sizes and covers a capacity range from approximately 4 kW to 38 kWZH heating compressors are optimised for low evaporation temperatures, deliver high heating capacity and efficiency, and thus reduce the need for supplementary electric or gas-fired heating – resulting in correspondingly better seasonal efficiencyVariants with ‘Enhanced Vapour Injection’ (EVI) feature an additional connection for vapour injection during compressionThis extends the heating capacity and operating range and enables high flow temperatures, often making them suitable as a replacement for conventional boilersAxial and radial flexibility of the scrolls ensures high reliabilityHigh efficiency and increased heating capacity, even at low source temperaturesHigh water temperatures for various heating systemsLow noise and vibration levelsTandem configurations possible for improved seasonal efficiencyExtended vapour injection (EVI) for maximum output and efficiencyMaximum permissible operating pressure (PS): ZH(i)04K1P to ZH(i)23K1P: ND 28 bar(g) / HD 45 bar(g)Maximum permissible operating pressure (PS): ZHi27K1P to ZHi46K1P: ND 29.5 bar(g) / HD 53 bar(g)Maximum permissible operating pressure (PS): ZH12K4E to ZH45K4E: ND 20 bar(g) / HD 32 bar(g)Maximum permissible operating pressure (PS): ZH09KVE to ZH18KVE: ND 20 bar(g) / HD 32 bar(g)Technical detailsDimensions (length × width × height) 24.4 × 24.1 × 43.8 cmApplication range HBPApplication range HTNumber of phases 3Design: HermeticCOP 3.61dB(A) @ 1 m 67dB(A) 78Pressure line (inches) 1/2"Electronics includedFrequency 50–60 HzWeight 40Displacement 17.1 m³/hCooling capacity (kW) 18.75Refrigerant R407CCapacity under operating conditions: 7.2°C evap, temp; 54.4°C cond, temp; R407C at 50 HzPower consumption [kW] 3.67Max. operating current (A) 14Max. operating pressure (low/high) [bar(g)] 22.6/32Motor code TFDOil pre-filledOil capacity (l) 1.90Oil type POEProduct family ZHSuction line (inches) 7/8"Compression type: ScrollSupply voltage 380–420 VSupply voltage 460VAdvantages and benefitsHigh efficiency and heating output, even at low source temperaturesLow noise and vibration levels for quiet operationOptimised for low evaporation temperatures, which reduces the need for supplementary heatingTandem combinations possible to improve seasonal efficiency Note:Oil: The compressor is pre-filled with oil at the factory. Refrigerant is not included and must be charged by a qualified contractor.Electronics: The electronics are included in the scope of supply.
