Compressor Dorin H300CS-E, MBP - R404A, R407C, R507, HBP - R134a
47-32H300CS-E
Product number:
47-32H300CS-E
Manufacturer:
Dorin
Manufacturer number:
H300CS-E
Weight:
61 kg
Do you have some questions about this product?
- Your personal contact person
- Andrey Chudinov
- [email protected]
- +49 2554 912 983 9
- Nicht das gefunden wonach Sie suchen?
Downloads
- 47-32H300CS-E-Datasheet-HHKaeltetechnik - Datenblatt / Datasheet
Description
Product information "Compressor Dorin H300CS-E, MBP - R404A, R407C, R507, HBP - R134a"
Dorin H300CS-E semi-hermetic compressor (first oil - POE 32) for 47-32H300CS-E
Introduction: The Dorin H300CS-E semi-hermetic compressor is the ideal successor to the tried-and-tested Dorin H300CS compressor. With its versatile application options and impressive performance, this compressor is perfect for use in refrigeration, air conditioning and ventilation technology as well as in heat pumps.
Technical details:
- HBP - R134a, MBP - R404A, R407C, R507
- Voltage: 380-420V(Y)/3/50Hz
- FLA: 7.5A
- Starting current LRA: 34.1A
- 2 cylinders
- Delivery volume: 15.94 m3/h
- Maximum test pressure: 22LP/30.5HP bar
- Oil filling: 1.4 kg
- Connections: Suction valve: 28s mm, pressure valve: 16s mm
- Net weight: 54 kg
- Dimensions (LxWxH): 400 x 255 x 310 mm
- Evaporation temperature (R134a): +10°C to -20°C
- Evaporation temperature (R404A/R507): -5°C to -40°C
Advantages and benefits:
- Impressive performance for various refrigerants
- Compact design for space-saving installation
- Reliable and durable technology for long-term efficiency
Refrigeration capacity measured for condensation temperature of 45°C, refrigerant R134a, frequency 50 Hz, measuring conditions: EN12900
Downloads
- 47-32H300CS-E-Datasheet-HHKaeltetechnik - Datenblatt / Datasheet
Properties
| Condensation temperature: | 45 °C |
|---|---|
| Connection Size: | 16 mm |
| Conveyance volume: | 15.94 |
| Delivery and suction volume (m3): | 15,94 |
| Design: | Design, Reciprocating piston |
| Dimensions ( length × width × height ): | 40.00 × 25.50 × 31.00 cm |
| Equipment: | 2-cylinder |
| Field of application: | MBP/HBP |
| Kompressortyp: | Reciprocating piston |
| Measuring conditions: | EN12900 |
| Oil quantity (l): | 1,6 |
| Pressure line (mm): | 16 |
| Refrigerant: | R407C, R507, R507A |
| Scope of application: | MBP/HBP |
| Suction line (mm): | 28 |
| Voltage: | 380-420V |
| cooling capacity (W) at To 0°C: | 7030 |
Manufacturer
Dorin
Officine mario dorin s.p.a. is an italian family business (founded in compiobbi in 1918), high-quality refrigeration and air conditioning technology from 1932 and is today one of the world's leading manufacturers of semi-nutretic compressors and condensing sets. the company with branches in 55 countries provides about 4,000 compressors per month and generates sales of around eur 35 million annually. officine mario dorin s.p.a. offers its international customers a complete range of semi-nutretic, open and two-stage compressors. overall, more than 70 models are available with nominal outputs between 0.4 hp and 150 hp for use with fully and partially halogenated refrigerants. technically perfect semi-thermetic compressor of the dorin brand work highly efficient even with extreme operating conditions. dorin compressors are characterized by efficiency, reliability and robustness as well as extra-high quality. quality represents part of the company philosophy: "the important thing is that our products are always perfect" (mario dorin). the valve plates for dorin compressors are manufactured by hoerbiger kompressortechnik gmbh. dorin product range was certified by lloyd's register quality assurance to iso9001-2000 (lrc 170322). all compressors comply with the european policies: en 292-1 / -2, en 294, en 60204, pren 349, en 60529, iec 336-1 and iec 335-2-34. the structure of the type number of dorin compressors is as follows :
